Rackmount chassis Server case 19 inch mini-itx 1U N130

Drives1* 3.5 or 2* 2.5"(Int.)+1* Slim 5.25 for optical device

Motherboard Size 6.7 * 6.7 (mini-ITX)

Dimension19 * 1.75 * 11.8 inches / 482 * 44.5 * 300 (mm)

Inquiry

DESCRIPTION

VIDEO

1U Rackmount mini-itx Chassis support slim 5.25 optical device+two full PCI slot expansion


Introduction

This 1U rackmount chassis Its unique thermal cooling solution fan can cool the system down while it runs at optimal level. unique universal aluminum I/O plate enables standard I/O backplane for Mini-itx motherboards.  three internal 3.5" and two 2.5" provide the meet regular server system applications


Model Number           KI-N130
Dimension (W*H*D) 19" x 1.75" x 11.8"/ 482 x 44 x 300 (mm)
Motherboard Size 6.7" x 6.7" (Mini ITX)
Drive Bays 1 x slim 5.25 + 1 x 3.5" or 2 x 2.5" (int.)
Indicators LEDs for Power & HDD
Switches 1 x Power +1 x Reset
PSU Type

 1U Flex PSU

Expansion Slots 2 slot PCI slot (for many kinds of riser card)
Material of Front Bezel  Aluminum
Material of Handle Aluminum
Material Construction Heavy-duty & Rugged SGCC steel 1.0mm
Sliding rail 18" 1U ball bearing sliding rail (option)
Color of Main Chassis  Black
Front Connector 2 x 2.0 USB
Fan: 2 x 4cm fan
Packing size CBF / CBM 1.8 / 0.05
Packing N.W / G.W    3.7KGS / 4.5KGS
CPU Cooler1U CPU Cooler LGA 115x socket (option)
