Rackmount chassis Server case 19 inch microATX 2U N240L

Drives5.25 * 1+3.5 * 4 (Int.)

Motherboard Size 9.6*9.6 (microATX,mini-ITX)

Dimension19 * 2U * 15.7 inches 482 * 88.9 * 400 mm



2U Compact Rackmount microATX Chassis ATX Power Supply Compatible

  • Industrial compact chassis with 15.75" depth
  • Supports standard ATX power supplies
  • 2 x front access USB 2.0 (option USB3.0 with 2.0 adaptor)
  • Supports 4x low-profile add-on cards

  • The most economic 2U chassis with one 5.25" + four 3.5" bays


KI-N240L is a reliable and stable 2U-high industrial computer chassis.

1x CDROM space for wide range application, like fan control+4x3.5" HDD,

The full size I/O supports all microATX motherboard with a

Dual-core/ Quad-Core CPU and the backplane supports 4 low profile add-on

cards. it is only 15.7" deep, has  two intake 80mm cooling fans at front for air ventilation.

In addition, it supports a standard ATX power supply with any fan type (12cm or 8cm both OK)

Model Number           KI-N240L
Dimension (W*H*D) 19" x 2U x 15.7"/ 482 x 88 x 400 (mm)
Motherboard Size 9.6" x 9.6" (Micro ATX or Mini ITX)
Drive Bays 1 x 5.25" + 4 x 3.5" (int.)
Indicators LEDs for Power & HDD
Switches 1 x Power +1 x Reset
PSU Type

Wide range PS-2 PSU which with12cm or 8cm fan both OK Support obverse or reverse installation

Expansion Slots4 (low profile)
Material of Front Bezel Aluminum
Material of HandleAluminum
Material ConstructionHeavy-duty & Rugged steel 1.2mm
Sliding rail18" ball bearing sliding rail (option)
Color of Main ChassisBlack
Front Connector 2 x 2.0 USB (option 2xUSB3.0 with 2.0 adaptor)
Optional Fan: 2 x 8cm two ball bearing
Packing size CBF / CBM 2.3 / 0.065
Packing N.W / G.W5.5KGS / 6.5KGS
